6048/03 FG Secondary crown gear 74 Teeth
Genuine FG spare/option part. ClutchGear shaft outerGear shaft innerDifferentialReduction ratio345823735,41345823745,49345824735,19345824745,26355823735,26355823745,33355824735,04355824745,11365823735,11365823745,18365824734,90365824744,97375823734,98375823745,04375824734,77375824744,84Contents:1 piece
6048/04 FG Secondary crown gear 73 Teeth
Genuine FG spare/option part. ClutchGear shaft outerGear shaft innerDifferentialReduction ratio345823735,41345823745,49345824735,19345824745,26355823735,26355823745,33355824735,04355824745,11365823735,11365823745,18365824734,90365824744,97375823734,98375823745,04375824734,77375824744,84Contents:1 piece
6425/01 FG Stabilizer front/rear for 1/6 scale models
Genuine FG spare/option part.Fits for all 1:6 scale models except Monster-Truck, Monster Beetle Pro and Stadium-Truck. Not suitable for all 4WD cars.Dimensions:Front: 3 mmRear: 4 mmContents:1 set
6427 FG Plastic gear wheel 46 teeth - 1pce.
46 teeth gear wheel for the layshaft.Diameter 72 mmWidth 15.5 mmTooth width 12 mmModule: m=1,5
6427/01 FG Plastic gear wheel 46 teeth 2-speed
Genuine FG spare/option part. 46 teeth gear wheel for the layshaft with 2-speed gear box.Dimensions:Diameter: 72 mmWidth: 15.5 mmTooth width: 12 mmModule: m=1,5Contents:1 piece
6429/01 FG Upright front for 1:6 2WD models
Genuine FG spare/option part.Reinforced version with steel inlay to prevent the M5 bolts from being pulled out.Bearing seats: 22 x 7 mm.Contents:2 pieces
6430/01 FG Tuning upright rear left/right for 1:5 and 1:6 models - 2pcs.
Inserted steel ring prevents ripped threads for the M5 boltBearing seats 22x7 mm
6431 FG Steel pinion 16 teeth
Genuine FG spare/option part.For combination with 48T main and differential spur gear.Diameter: 26.7 mmBore: 10 mmTotal width: 16 mmTooth width: 9.5 mmModule: m=1,5Contents:1 piece
6431/01 FG Steel pinion 16 teeth, wide - 1pce.
Item N° 6431/01 Steel pinion 16 teeth, wide - 1pce.For use on the clutch bell of FG monster cars.Diameter 26.7 mmBore 10 mmTotal width 18 mmTooth width 11.5 mmModule: m=1,5
6432 FG Steel pinion 18 teeth - 1pce.
Item N° 6432 Steel pinion 18 teeth - 1pce.For combination with 46T main spur gear.Diameter 29,7 mmBore 10 mmTotal width 18 mmTooth width 11.5 mmModule: m=1,5
6432/01 FG Steel pinion 18 teeth 2-speed - 1pce.
Item N° 6432/01 Steel pinion 18 teeth 2-speed - 1pce.For combination with 46T main spur gear on 2-speed spur gear only.Diameter 29.7 mmBore 10 mmTotal width 16 mmTooth width 9.5 mmModule: m=1,5
6432/02 FG Steel pinion 19 teeth - 1pce.
Item N° 6432/02 Steel pinion 19 teeth - 1pce.For combination with 44T main spur gear.Diameter 32.7 mmBore 10 mmTotal width 18 mmTooth width 11.5 mmModule: m=1,5Profile regraded, this means that the number of teeth is changed while the diameter remained constant. The part of the involutes? curve that defines the tooth profile is changed. Positively regraded (lower number of teeth) pinions are stronger and run smoother, the reduced strength of negatively regraded pinions doesn?t really matter.
6432/17 FG Steel gearwheel 17 teeth, profile displaced, 1 pce.
Item N° 6432/17 Steel gearwheel 17 teeth, profile displaced, 1 pce. True running steel pinion for minimized wear. Suitable for all FG cars except Formula 1. Profile regraded, this means that the number of teeth is changed while the diameter remained constant. The part of the involute curve that defines the tooth profile is changed. Positively regraded (lower number of teeth) pinions are stronger and run smoother, the reduced strength of negatively regraded pinions doesn't really matter.
6433 FG Steel pinion 20 teeth - 1pce.
Item N° 6433 Steel pinion 20 teeth - 1pce.For combination with 44T main spur gear.Diameter 32.7 mmBore 10 mmTotal width 18 mmTooth width 11.5 mmModule: m=1,5
6433/21 FG Steel gearwheel 21 teeth
Genuine FG spare/option part.For an optimal gear adjustment, suitable with gearwheel 44 teeth.Dimensions:Diameter: 32,7 mmContents:1 piece
6433/23 FG Secondary gears 23 teeth
Genuine FG spare/option part. ClutchGear shaft outerGear shaft innerDifferentialReduction ratio345823735,41345823745,49345824735,19345824745,26355823735,26355823745,33355824735,04355824745,11365823735,11365823745,18365824734,90365824744,97375823734,98375823745,04375824734,77375824744,84Contents:1 piece
6433/24 FG Secondary gears 24 teeth
Genuine FG spare/option part. ClutchGear shaft outerGear shaft innerDifferentialReduction ratio345823735,41345823745,49345824735,19345824745,26355823735,26355823745,33355824735,04355824745,11365823735,11365823745,18365824734,90365824744,97375823734,98375823745,04375824734,77375824744,84Contents:1 piece
6436 FG Rim extension white - 2pcs.
To use with FG part no. 6105, 6105/1 to come to the 80th width. The extension ring must be glued onto the rim.Bulk:Diameter: 120 mmWidth: 27 mm
6437/05 FG Tire insert for slicks 63 mm 1:6
Genuine FG spare/option part.Fits for the 1/6 scale front tires. Dimensions:Width: 55 mmHeight: 13 mmLength: 385 mmContents:2 pieces
6438/05 FG Tire insert for slicks 80 mm 1/6
Genuine FG spare/option part.Fits for 1/6 scale slick tires. Dimensions:Length: 380 mmWidth: 73 mmHeight: 13 mmContents:2 pieces
6439 FG Alloy spur gear carrier 60 mm
Genuine FG spare/option part. For 48T - 46T spur gears.Contents:1 piece
6440 FG Ball stabilizer for front axle Leopard - set
Ball stabilizer for the front axle of the Race Buggy Leopard. The stabilizer is much more effective than the conventional sway bar according to its direct fastening. Wire diameter 4 mm.1 set
