Genuine HT spare/option part.Wheel squares made of high-strength aluminum, hardened, with two M6 mounting threads Suitable for most 1/6 and 1/5 rc-cars. Through the use of two 6 mm screws a significantly higher retention force is achieved. Yet it is still recommended to use medium strength thread lock (link y0114)! The hard anodizing (HART-COAT) guarantees much lower wear of the squares! Especially recommended when using wheel mounted brake discs! Four 3x16 dowel pins per square are included which prevent the squares from spinning in the rim. Press fitting them into the wheel squares is optional. The 12, 14 and 17 mm wide squares feature a groove for inserting a C-clip (link 6106/05), which acts as a guide for the brake disk. The narrow 9.5 mm wide squares dont need a clip; the close sitting rim will guide the disk. Measures18 mm square (wheel drive!)9,5 mm wide, 8.0 mm diameter axle boretwo M6 mounting threads The set includes 2 pieces of 9,5 mm wide wheel squares and 4 pieces each of M6 grub screws and 3x16 dowel pins.Contents:2 pieces
Cable: 305 mmSheath: 220 mmSpare part for , , , , and .
Genuine HT spare/option part.Wheel squares made of high-strength aluminum, hardened, with two M6 mounting threads Suitable for most 1/6 and 1/5 rc-cars. Through the use of two 6 mm screws a significantly higher retention force is achieved. Yet it is still recommended to use medium strength thread lock (link y0114)! The hard anodizing (HART-COAT) guarantees much lower wear of the squares! Especially recommended when using wheel mounted brake discs! Four 3x16 dowel pins per square are included which prevent the squares from spinning in the rim. Press fitting them into the wheel squares is optional. The 12, 14 and 17 mm wide squares feature a groove for inserting a C-clip (link 6106/05), which acts as a guide for the brake disk. The narrow 9.5 mm wide squares dont need a clip; the close sitting rim will guide the disk. Measures18 mm square (wheel drive!)14 mm wide, 8.0 mm diameter axle boretwo M6 mounting threads The set includes 2 pieces of 14 mm wide wheel squares and 4 pieces each of M6 grub screws and 3x16 dowel pins.Contents:2 pieces
Length 12 mmInner diameter 3.3 mmWire diameter 0.3 mmSpare part for , , , , , , , , , , and .
Genuine HT spare/option part.Wheel squares made of high-strength aluminum, hardened, with two M6 mounting threads Suitable for most 1/6 and 1/5 rc-cars. Through the use of two 6 mm screws a significantly higher retention force is achieved. Yet it is still recommended to use medium strength thread lock (link y0114)! The hard anodizing (HART-COAT) guarantees much lower wear of the squares! Especially recommended when using wheel mounted brake discs! Four 3x16 dowel pins per square are included which prevent the squares from spinning in the rim. Press fitting them into the wheel squares is optional. The 12, 14 and 17 mm wide squares feature a groove for inserting a C-clip (link 6106/05), which acts as a guide for the brake disk. The narrow 9.5 mm wide squares dont need a clip; the close sitting rim will guide the disk. Measures18 mm square (wheel drive!)17 mm wide, 8.0 mm diameter axle boretwo M6 mounting threads The set includes 2 pieces of 17 mm wide wheel squares and 4 pieces each of M6 grub screws and 3x16 dowel pins.Contents:2 pieces
Genuine FG spare/option part.Dimensions:Inner diameter: 2 mmCollet outer diameter: 7 mm x width 5 mmOuterdiameter: 5 mm x width 8 mmContents:4 pieces
Cable: 350 mmSheath: 270 mmSpare part for , , , , and .
Top quality epoxy P-R-M Race brake discs with 10 dirt slots for removing dirt and abrasion, which will be transferred to the outside by the discs rotation. The epoxy P-R-M Race brake disc provides an optimal deceleration of the car without the unwanted fading (poor braking performance due to increased heat buildup)! The best braking action when using the epoxy P-R-M Race brake disc is achieved by the combination of the epoxy brake discs and steel brake pads (8456 or y19218). The epoxy P-R-M Race brake discs fit mechanical front and rear brakes on FG / Smartech / Carson cars with brake pads 8456 recommended for these applications.1 pair (2 pieces) Dimensions: Outer diameter: 60 mm Thickness: 2 mmsocket for 18 mm square wheel drive
Genuine HT spare/option part.Wheel squares made of high-strength aluminum, hardened, with two M6 mounting threads Suitable for most 1/6 and 1/5 rc-cars. Through the use of two 6 mm screws a significantly higher retention force is achieved. Yet it is still recommended to use medium strength thread lock (link y0114)! The hard anodizing (HART-COAT) guarantees much lower wear of the squares! Especially recommended when using wheel mounted brake discs! Four 3x16 dowel pins per square are included which prevent the squares from spinning in the rim. Press fitting them into the wheel squares is optional. The 12, 14 and 17 mm wide squares feature a groove for inserting a C-clip (link 6106/05), which acts as a guide for the brake disk. The narrow 9.5 mm wide squares dont need a clip; the close sitting rim will guide the disk. Measures18 mm square (wheel drive!)12 mm wide, 8.0 mm diameter axle boretwo M6 mounting threads The set includes 2 pieces of 12 mm wide wheel squares and 4 pieces each of M6 grub screws and 3x16 dowel pins.Content:2 pieces
Genuine FG spare/option part. Spare part for :6250/018450/0184521045010451Content:4 pieces
Genuine FG spare/option part. Spare part for:6250/016250/026250/056250/068450/018450/0584528452/0510450104511045210453Content:2 pieces
Hardened steel bushes for all caliper of the front and rear disk brakes. In combination with a ball-beared guide plate optimal position of the brake eccentric.Substitute for , , , , and .
Stud bolt with double sided thread for well-running brake linings, no jamming of the brake linings possible. Suitable for all mechanical disk brakes.
Genuine FG spare/option part. New competition brake lining with good braking characteristics and low wear. Glued on a steel plate.Spare part for: 6250/05, 6250/06, 8450/05, 8452/05, 10452, 10453 and y0056 HT - Baja 5B/SS premium front disk brake.Measures:Length approx. 50 mmWidth approx. 10 mmThickness approx. 5.5 mmMounting hole distance 40 mmContents:4 pieces
Cable: 225 mmSheath: 150 mmSpare part for , , , , and .
Genuine FG spare/option part. Spare part for:6250/016250/028450/0184521045010451Content:2 piece
Spare part for , , , , , , , , , , and .Thread size M6x17Bore 2 mmWrench size 8 mmTotal length 25 mm
Genuine FG spare/option part. Center hole distance 16 mm.Spare part for:6250/016250/028450/0184521045010451 Content:2 pieces
Revised alloy bowden cable holder short with longer brake lever distance according to the sinking of the pressure spring.Hole center distance 11 mm
Spare part for , , , , , , , , , , and .
Genuine FG spare/option part. Solid alloy brake lever for the bowden cable brakes, a twisting of the brake lever isn't possible anymore. Suitable for the long bowden cable holder.Length of effective lever 37 mm.Content:2 pieces
Alloy guiding plate for brake disk, ball beared.Substitute for , , , , and .Content:2 pieces
