55 products found for "y1013"
rc-car-online - Home
With 32 cm³ and 30% more power than the Zenoah G290.Significantly more torque and higher stamina due to larger sized bearings all around, with Racing Carburetor Walbro WT1107.The motor is supplied with WT-1107 carburetor and spark plug.SpecificationType: Two stroke gasoline engineDisplacement: 31,8 cm³Bore: 38 mmStroke: 28 mmWeight: 2,3 KgOverall Dimension:Length: 167 mmWidth: 215 mmHeight: 196 mmMaximum Output: 4,6 PSMaximum Torque: 2,00 N-mRotation Direction: CounterclockwiseCarburetor: Walbro WT-1107Spark plug: CMR7HStarting: Recoil starterFor all HPI Baja 5 cars the G320RCer clutch housing has to be shortened at the mounting base, for Losi 5ive- T and Desert Buggy XL cars the clutch housings overall length must be shortened to CY size.With the new "K & N" version of the Losi DBXL there is another detail, which need to be considered.From the very beginning the hole pattern for the engine installation in the DBXL chassis plate was no precise match to the hole pattern of the engine, even when delivered in stock form with standard engine. Now with the "K&N" version the engine mount has been changed to eliminate this discrepancy. However, all aluminum engine mounts available on the market share their dimensions with the previous plastic engine mount. For the installation of a G320 Zenoah in a "K&N" -DBXL two possible combinations exist in order to obtain the correct hole pattern:When using the standard (new) plastic engine mount a shortened clutch housing is required as in a 5ive-TWhen using an aluminum engine mount a stock length clutch housing is requiredSeparately, it is recommended to enlarge the cutout in the body panel in front of the K & N air filter for about 2 - 3 mm to ensure that the panel cannot chafe on the air filter.When installing the air filter you must pay attention to the length of the screws.For use on Losi and HPI we recommend M5x45 screws (like H94763); you can also cut existing screws to length, of course.When ordering with a modified clutch housing we will include these screws!In our shop you can select from Zenoah G320RC engines already modified to fit your HPI or Losi car.The installation of the Zenoah G320RC in other cars (like FG or Smartech buggies / monsters a.s.o.) is not even remotely straightforward, since the layshaft pinion (the small pinion in front of the big differential spur gear) is in the way for the larger Zenoah G320RC crankcase.Compatibility Zenoah / Losi 5ive-T:Please note that for installation in a Losi 5ive the fan cover must be swapped for a Losi or CY cover #5341 in order to fit the chassis" bolt pattern.If you want to install a Zenoah engine into the Losi 5ive, you usually have to use a fan cover from the CY engine.However, there is a workaround to maintain Zenoah fan cover.The adjustment is done via the pinion specific mounting plates for the engine. The change always affects only the rear, outer (carburetor side) plate under the fan cover. This is rotated by 180°; so that the embossed number on this plate faces the exhaust side of the engine!18T pinion: use 20T plate, rotated 180°19T pinion: use 19T plate, rotated 180°20T pinion: use 18T plate, rotated 180°On the plus side you gain the opportunity to easily mount a Zenoah engine keeping the original fan cover. On the other hand there will be the disadvantage of the necessity to combine two different sets of engine mounting plates when installing any pinion other than the stock 19T version. Therefore we do not recommend this workaround for everyday use. Nevertheless it works perfectly should ever the need arise. Attention! We recommend to run exclusively fully synthetic 2-stroke engine oil, like y0813 Motul 800 racing oil.
Genuine Motul spare/option part. High-cling oil for foam cartridge air filters, especially for offroad and street use. The oil reinforces the the air filter'e efficiency and retains dirt, mud and sand particles, which will greatly extend the life of the engine. The blue tint makes it easier to control even oil application to the filter.Apply oil to filter generously and work the foam vigorously by hand to ensure complete oil penetration. Press foam slightly to remove excessive oil when done.Contents:1 piece / 400 ml
Content: 400 Milliliter (€47.25* / 1000 Milliliter)
Genuine HT spare/option part.Reinforces the front suspension and doubles the mounting plate for the shock tower.Contents:1 piece
connector straight for all hydraulic brake linings with a outside diammeter of 4mm. e.g Colari, Magura II and Mecatech.Connecting thread M5
26 cm³ Zenoah engine for large scale cars!Please note: contrary to their new designation the displacement has not been increased! The outer dimension didn't change, so you don't need any additional parts for the engine swap!The engines feature the following improvements over their G260RC:Quantity of cylinder mounting bolts increased from 2 to 4Improved strength of crankcaseAdded additional bearing on the PTO (clutch) side of crankshaftRedesigned shape of cylinder finsDimension of air intake port is 5% widerNew carburetor (WT-990) Contains internal fuel pump which increases acceleration from idle to wide open throttle.Removal of choke valve increases performance by increasing air flow to the carburetor Changed material of the insulator gasket to metal, which improves sealing performanceThe engine will be delivered with pull starter, carb and spark plug / spark plug cap. Genuine Zenoah air filter and / or complete clutch and / or ball beard carburetor are optionally available at additional charge. Compatibility Zenoah / Losi 5ive-T:Please note that for installation in a Losi 5ive the fan cover must be swapped for a Losi or CY cover #5341 in order to fit the chassis" bolt pattern.If you want to install a Zenoah engine into the Losi 5ive, you usually have to use a fan cover from the CY engine.However, there is a workaround to maintain Zenoah fan cover.The adjustment is done via the pinion specific mounting plates for the engine. The change always affects only the rear, outer (carburetor side) plate under the fan cover. This is rotated by 180°; so that the embossed number on this plate faces the exhaust side of the engine!18T pinion: use 20T plate, rotated 180°19T pinion: use 19T plate, rotated 180°20T pinion: use 18T plate, rotated 180°On the plus side you gain the opportunity to easily mount a Zenoah engine keeping the original fan cover. On the other hand there will be the disadvantage of the necessity to combine two different sets of engine mounting plates when installing any pinion other than the stock 19T version. Therefore we do not recommend this workaround for everyday use. Nevertheless it works perfectly should ever the need arise. Attention! We recommend to run exclusively fully synthetic 2-stroke engine oil, like y0813 Motul 800 racing oil.
Genuine MadMax spare/option part.Losi and HPI foam tire inserts from can be used.The OVER LANDER MadMax are designed as all-terrain tires that can be used on virtually all surfaces because of its tightly attached lug tread pattern When a terrain includes sand, gravel and grass, the OVER LANDER is the right choice! It can even be used on partially paved tracks! Dimensions:Outer diameter: 170 mmTyre width front: 60 mmTyre width rear: 80 mmContents:4 pieces / 2 pairs Some off-road tires knowledge can be found here!
%
The sets include:Item N°Name:y1027HT Aluminum a-arm 2WD, front uppery1026HT Aluminum a-arm 2WD, front lower, one-piecey1028HT Aluminum front bulkhead A for 2WDy1030HT Aluminum front bulkhead B for 2WDy1036HT rose joints with conical spacersy1029HT aluminum droop stopsy1032HT Aluminum shock tower Marder 2WDy1031HT Aluminum bulkhead brace for 2WDUnit prices: 391,00 EURThe sets include complete front bulkheads A + B with brace, upper (adjustable) and lower a-arms and shock tower.Please note: the hinge pins are not included, you will use the pins from the stock suspension!Fits FG Marder, Beetle, Pajero and Monster Beetle.
Inner diameter 6 mmOuter diameter 8 mmWidth 6 mm
Alloy rear axle conversion kit for Smartech UNO and Carson Attack and Super Attack (not Evo!), Gas Blaster and C5; Smartech Spider and Ranger cars.Fits for:- C5 / On road / Touring car- C6 Attack- Touareg- Super Attack- Gas Blaster- Duratrax Firehammer- Spider- Big AttackThe set includes:- rear plate- differential mounts- lower a-arms- upper a-arms- installation hardware.Please note: must use inge pins 6075, also you need two packets turnbuckle 40 mm 6100/04.
y1103 Size:
y1103/01 - Small
Genuine HT spare/option part. You can select from two different sizes of body support.Dimensions small body support y1103/01:Length: approx. 80 mmWidth: approx. 16 mmDistance bore to bore: approx. 64 mmDimensions large body support y1103/02:Length: approx. 105 mmWidth: approx. 16 mmDistance bore to bore: approx. 88 mmBore diameter: approx. 8 mmContents:2 pieces
kleb_0005 Strength:
y0113/02 High+ 2EUR
Genuine HT spare/option part.Available as 272 high strength and heat resistant, 270/1 high strength or 241 medium strength.The strength of 272 and 270/1 is comparable, but 272 can handle temperatures up to 230°C vs. 150°C for 270/1. It is therefore the perfect choice for applications like exhaust or clutch pinion bolts. However, curing of 272 takes at least twice as long as 270/1.An excellent recommendation for removal of screws treated with threadlocking compound:CFH Diamant M50 Gasbrenner, y1007 Contents:1 piece / 10 gram
Content: 20 Gramm (€495.00* / 1000 Gramm)
Variants from €7.90*
%
Genuine K&N spare/option part. The K+N air filter oil is only suitable for all K+N air filters, foam preliminary filters and filter inserts.Content:1 piece / 204 ml
Content: 204 Milliliter (€78.97* / 1000 Milliliter)
y1613 Version:
Version
Genuine rc-car-online spare/option part.The optimal parking lot or race tires for your FG Racetruck model.Type Width Outer diameterFront 64 mm 153 mmRear 78 mm 153 mmGlued on original FG-Racetruck rims (rear tire with extension to the inside), incl. foam rubber insert,FG rim with 18 mm square drive and reinforcement ring.Attention: From experience we warn against using rims and extensions from another manufacturer.Since the Mammoth tires provide a very good grip, the rim and bonding are extremely stressed. Due to the high torque load in relation to the bonding of tires on large models, an occasional check in this regard and possibly a repair of the bonding (y0067) is inevitable.As a recommendation:The dirtier the track or the colder the temperature, the softer the rear tire should be.Reference for the front tire: With 2WD models this should be one to two stages harder than the used rear tire. On 4WD models, a tire combination with the same shore hardness front and rear is often good to drive.Of course, with Mammoth Supergrip Racetruck tires, the softer the tire, the higher the wear.The Mammoth Supergrip Racetruck tires have a special onroad tread. Whereby these still have an optimal grip after the wear of the tread, and can still be driven for a long time.
Offerset:2 Pairs MadMax Maxi Pin tires2 Pairs MadMax rims2 Pairs MadMax inlays2 Pairs / 4 pieces adapter TT1020/01MAXI PIN 185 x 75 with black colored MadMax Extreme rims, 20-fold screwed, very tough, with 24 mm hex drive and with reinforced orange beadlock rings for Losi and HPI. The MadMax MAXI PIN tires come with strong special tire inserts which allow transferring the power without canting, even on heavy cars. MadMax MAXI PIN tire was developed specifically for astro turf tracks! The special tread design with 480 studs per tire provides excellent grip, but also a high load on tire and rim! To stabilize the tire, the outer shoulder features radial ribs which minimizes the tilting under load and counteract the shear forces during cornering. Furthermore, the MAXI PIN tire has studs positioned on the outside shoulder, which support the steering in corners. All together the MAXI PIN tires provide maximum grip, which made it necessary to upgrade the beadlock screws on these MadMax EXTREME wheels. So they come with 3.0 mm screws instead of the usual 2.5 mm ones! Nevertheless, tires and beadlocks should be checked after every run.The set consists of four tires, including tire inserts and MadMax EXTREME rims and 4 pieces adapter wheel nuts TT1020/01. Dimensions: Outer diameter: 185 mm tire width at bead: 70 mm Tread width: 75 mm Reinforced 24 mm hex wheel drive The video shows the 18 mm square drive version. Also available with 24 mm hex. Some off-road tires knowledge can be found here!TT1020 Top Tuning Adapter wheel nutGenuine TopTuning spare/option part.These adapter nuts, manufactured from billet 7075 aluminum allow for easy and precise installation of all MadMax, HPI and Losi tires and rims on the Traxxas X-Maxx. For the best result possible, nut and adapter are manufactured as a one-piece unit.It should be noted that the wide rims can be used on the rear axle only. On the front axle they would limit the steering angle by grinding on lower a-arm and steering rod.Traxxas has microencapsulated the wheel shafts of the X-Maxx to secure the wheel nuts. Like any thread locking compound this is not for eternity. After several tire changes the use of a normal screw locking compound is advised, we recommend it "y0113 / 01 medium strength".The dimensions of the nut are specifically designed for use with MadMax, current HPI and Losi rims. Rims from Losi 5ive have slightly different dimensions in the hub area. This is meaningless on the large LOSI or HPI wheel adapters. With the smaller and shorter wheel nut thread of the X-Maxx wheel shafts you cannot compromise. Therefore there are also special nuts for the Losi rims/wheels available at our options menu.However, somewhere in the past, the injection moulds for the HPI rims were slightly modified in the hub area. As part of that job the bore diameter has probably been slightly increased. Therefore, the use of older rims in combination with the adapter nuts makes it necessary to increase the rim bore a little bit.Due to repeated requests for use: these wheel nuts replace the stock wheel nuts when installing the wheels!Contents:4 pieces
Offerset:1 Pair MadMax Cross Bond front tires 170x60 mm1 Pair MadMax Cross Bond rear tires 170x80 mm1 Pair MadMax front rims 60 mm1 Pair MadMax rear rims 80 mm1 Pair MadMax front inlays 60 mm1 Pair MadMax rear inlays 80 mm2 Pairs / 4 pieces adapter TT1020/01CROSS BOND 170 x 80 mm and 170 x 60 mm tires with black MadMax Extreme 20 bolt-beadlock rims with 24 mm hex drive and reinforced beadlock rings were designed for use on loose surfaces. The extremely rigid and differently structured lugs of the CROSS BOND ensure optimum power transmission and also allow for excellent grip on loose surfaces, such as sand and soil. The lugs are raised at the treads outside, and therefore provide maximum grip, particularly when cornering where the tire is canted to the outside. Due to the extreme load created by the MadMax CROSS BOND tires the rim was optimized again with a reinforcement ring.The tires are fitted with a special rigid insert, which can handle the cornering forces and maintain the tires shape even on heavy cars.The set consists of two each front and rear tires, including tire inserts and MadMax EXTREME rims and 4 pieces adapter wheel nuts TT1020/01. We recommend to check the beadlock screws after the run. Dimensions:Outer diameter: 170 mmFront tire width: 60 mmRear tire width: 80 mmReinforced 24 mm hex driveThe video shows the 18 mm square drive version. Also available with 24 mm hex. Some off-road tires knowledge can be found here!TT1020 Top Tuning Adapter wheel nutGenuine TopTuning spare/option part.These adapter nuts, manufactured from billet 7075 aluminum allow for easy and precise installation of all MadMax, HPI and Losi tires and rims on the Traxxas X-Maxx. For the best result possible, nut and adapter are manufactured as a one-piece unit.It should be noted that the wide rims can be used on the rear axle only. On the front axle they would limit the steering angle by grinding on lower a-arm and steering rod.Traxxas has microencapsulated the wheel shafts of the X-Maxx to secure the wheel nuts. Like any thread locking compound this is not for eternity. After several tire changes the use of a normal screw locking compound is advised, we recommend it "y0113 / 01 medium strength".The dimensions of the nut are specifically designed for use with MadMax, current HPI and Losi rims. Rims from Losi 5ive have slightly different dimensions in the hub area. This is meaningless on the large LOSI or HPI wheel adapters. With the smaller and shorter wheel nut thread of the X-Maxx wheel shafts you cannot compromise. Therefore there are also special nuts for the Losi rims/wheels available at our options menu.However, somewhere in the past, the injection moulds for the HPI rims were slightly modified in the hub area. As part of that job the bore diameter has probably been slightly increased. Therefore, the use of older rims in combination with the adapter nuts makes it necessary to increase the rim bore a little bit.Due to repeated requests for use: these wheel nuts replace the stock wheel nuts when installing the wheels!Contents:4 pieces
Offerset:1 Pair MadMax Ultragrip front tires 170x60 mm1 Pair MadMax Ultragrip rear tires 170x80 mm1 Pair MadMax front rims 60 mm1 Pair MadMax rear rims 80 mm1 Pair MadMax front inlays 60 mm1 Pair MadMax rear inlays 80 mm2 Pairs / 4 pieces adapter TT1020/01Ultragrip 170x80 and 170x60 on black MadMax Extreme rims with 20 beadlock screws, with 24 mm hex socket and reinforced silver headlock rings for Losi 5ive-T and Desert Buggy XL as well as all HPI Baja 5 cars.150 shifted long lugs and a central, 4 mm high ridge on the 60 mm wide front tire, and 210 pieces of square 6 x 4 mm studs on the 80 mm wide rear tire ensure optimal propulsion! The flattened profile structure of the rows of knobs reduces the directional control and guarantees an exceptionally good on-center feel! This makes the car less prone to unwanted traction rolls! Due to the extreme load created by the MadMax Ultragrip tires the rim was optimized again with a reinforcement ring. The tires are fitted with a special rigid insert, which can handle the cornering forces and maintain the tires shape even on heavy cars like the Losi 5ive-T.The set consists of two each front and rear tires, including tire inserts and MadMax EXTREME rims and 4 pieces adapter wheel nuts TT1020/01.We recommend to check the beadlock screws after the run. Dimensions:Outside diameter: 170 mmFront tire width: 60 mmRear tire width: 80 mmReinforced 24 mm hex wheel driveThe video shows the 18 mm square drive version. Also available with 24 mm hex. Some off-road tires knowledge can be found here!TT1020 Top Tuning Adapter wheel nutGenuine TopTuning spare/option part.These adapter nuts, manufactured from billet 7075 aluminum allow for easy and precise installation of all MadMax, HPI and Losi tires and rims on the Traxxas X-Maxx. For the best result possible, nut and adapter are manufactured as a one-piece unit.It should be noted that the wide rims can be used on the rear axle only. On the front axle they would limit the steering angle by grinding on lower a-arm and steering rod.Traxxas has microencapsulated the wheel shafts of the X-Maxx to secure the wheel nuts. Like any thread locking compound this is not for eternity. After several tire changes the use of a normal screw locking compound is advised, we recommend it "y0113 / 01 medium strength".The dimensions of the nut are specifically designed for use with MadMax, current HPI and Losi rims. Rims from Losi 5ive have slightly different dimensions in the hub area. This is meaningless on the large LOSI or HPI wheel adapters. With the smaller and shorter wheel nut thread of the X-Maxx wheel shafts you cannot compromise. Therefore there are also special nuts for the Losi rims/wheels available at our options menu.However, somewhere in the past, the injection moulds for the HPI rims were slightly modified in the hub area. As part of that job the bore diameter has probably been slightly increased. Therefore, the use of older rims in combination with the adapter nuts makes it necessary to increase the rim bore a little bit.Due to repeated requests for use: these wheel nuts replace the stock wheel nuts when installing the wheels!Contents:4 pieces
Genuine Zenoah spare/option part. Replacement part fits Zenoah G320RC.
Genuine Zenoah spare/option part. Replacement part fits Zenoah G320RC.Dimensions: Outer diameter: 9 mmInner diameter: 6mmLength: 32 mm
Genuine Zenoah spare/option part. Replacement part fits Zenoah G320RC.
Genuine Zenoah spare/option part. Replacement part fits Zenoah G320RC.
Genuine Zenoah spare/option part. Replacement part fits Zenoah G320RC.
Genuine Zenoah spare/option part. Replacement part fits Zenoah G320RC.
