TT70120/JS Top Tuning Beast Brushless Motor 620 kV, used

The engine is being sold on behalf of a customer and has only been driven one tank of fuel, because the customer has converted to electric drive.The original price of the motor is €899.Product information "y1610 SPEED TEC Expert 7-port Zenoah G320 modified engine"The SPEED TEC 7-port genuine Zenoah engine is optimized for performance by hand with sophisticated craftsmanship and guarantees, besides greatly increased performance, excellent workmanship and stamina.More power and torque through the three additional transfer ports.SPEED TEC V 7-port version modifications:Cylinder:Cylinder bottom modified for higher compressionenlarged and flow-optimized transfer portsmachining of three additional transfer ports raises number of ports from 4 to 7intake and exhaust ports optimized and matchedport timing modifiedCrankshaft:is adjusted, aligned and balancedFlywheel and ignition:Weight reduced and checked for run-out.Gaskets:Premium quality gaskets installed. Cylinder gasket installed using elastic gasket sealer.With the new "K & N" version of the Losi DBXL there is another detail, which need to be considered.From the very beginning the hole pattern for the engine installation in the DBXL chassis plate was no precise match to the hole pattern of the engine, even when delivered in stock form with standard engine. Now with the "K&N" version the engine mount has been changed to eliminate this discrepancy. However, all aluminum engine mounts available on the market share their dimensions with the previous plastic engine mount. For the installation of a G320 Zenoah in a "K&N" -DBXL two possible combinations exist in order to obtain the correct hole pattern:When using the standard (new) plastic engine mount a shortened clutch housing is required as in a 5ive-TWhen using an aluminum engine mount a stock length clutch housing is requiredSeparately, it is recommended to enlarge the cutout in the body panel in front of the K & N air filter for about 2 - 3 mm to ensure that the panel cannot chafe on the air filter.For all HPI Baja 5 cars the G320RCer clutch housing has to be shortened at the mounting base, for Losi 5ive- T and Desert Buggy XL cars the clutch housings overall length must be shortened to CY size.When installing the air filter you must pay attention to the length of the screws.For use on Losi and HPI we recommend M5x45 screws (like H94763); you can also cut existing screws to length, of course.When ordering with a modified clutch housing we will include these screws!In our shop you can select from Zenoah G320RC engines already modified to fit your HPI or Losi car.The installation of a Zenoah G320RC in a Smartech C5 onroad car is possible without modifications. However, due to the engines performance aluminum engine mounts (set # y0189) are mandatory!The installation of the Zenoah G320RC in other cars (like FG or Smartech buggies / monsters a.s.o.) is not even remotely straightforward, since the layshaft pinion (the small pinion in front of the big differential spur gear) is in the way for the larger Zenoah G320RC crankcase.Compatibility Zenoah / Losi 5ive-T:Please note that for installation in a Losi 5ive the fan cover must be swapped for a Losi or CY cover #5341 in order to fit the chassis" bolt pattern.If you want to install a Zenoah engine into the Losi 5ive, you usually have to use a fan cover from the CY engine.However, there is a workaround to maintain Zenoah fan cover.The adjustment is done via the pinion specific mounting plates for the engine. The change always affects only the rear, outer (carburetor side) plate under the fan cover. This is rotated by 180°; so that the embossed number on this plate faces the exhaust side of the engine!18T pinion: use 20T plate, rotated 180°19T pinion: use 19T plate, rotated 180°20T pinion: use 18T plate, rotated 180°On the plus side you gain the opportunity to easily mount a Zenoah engine keeping the original fan cover. On the other hand there will be the disadvantage of the necessity to combine two different sets of engine mounting plates when installing any pinion other than the stock 19T version. Therefore we do not recommend this workaround for everyday use. Nevertheless it works perfectly should ever the need arise.

SCOPE OF DELIVERY AND CONDITION SEE PHOTOS. THE ITEM IS SOLD ON BEHALF OF THE CUSTOMER. The item is in excellent condition. Scope of delivery and condition see photos. VRC TUNING PIPE LOSI DESERT BUGGY XLThis VRC exhaust fits the lower mentioned models with engines from 23 to 29 cc.VRC, Victory RC, exhausts guarantee a considerable power gain in the whole RPM. In general, the power of a standard engine is increased by more than one horsepower, and the low end torque by more than 1 Newton meter.Each pipe is made from thin sheet metal and welded and assembled entirely by hand. This VRC exhaust has an internal noise reducer and consists of several chambers for maximum performance. The very pleasant Race Sound and its volume can be compared to that of a Tuned scooter.Mounting tip; Slide the rubber hose over the pipe and mount the manifold and spring. Then mount the assembly hand-tight on the cylinder. If you know for sure that it is in the right place on the car, fix the pipe and mount the cable ties. We recomend to use the TPS6403/32 clambs.It often seems that the exhaust does not fit, but this is not the case. In the beginning there was a tight fit between the pipe and manifold, but due vibrations the cylinder that was fixed with 2 bolts, and/or the exhaust started to tear. Since a few years, that fit has been made wider to prevent this. But this does mean that the exhaust can move more, this also benefits the assembly on the car. Due to the strong spring the exhaust pulls in one direction, so it seems that the exhaust does not fit.Suitable for:LOSI DBXLLOSI DBXL K&NNB! VRC exhausts cannot be returned and/or exchanged due the possible rust building after handling/unpacking!

inclusive:Product information "TT56112/520 Top Tuning Monster Brushless Motor 520kV"Genuine Top Tuning spare/option part.SpecificationsMax. amps: 129 AMax. voltage: 57 VMax. power: 7,350 WKV (RPM/Volt): 520 KVMounting hole depth: 8 mmBolt pattern: 4 x M4 at 30 mm pitch circle diameterCase diameter: 57.8 mmCase length: 112 mmFree shaft length: 30 mmShaft diameter: 8 mmWeight: 1260 gConnector: 6.5 mm diameterCable size: 8AWGFeaturesHigh quality bearings4Pole rotor with high quality magnetsStator - super thin silicon steel layersSuper strength 8 mm shaftCNC Aluminium heatsink caseCopper wires with high temperature enduranceContents:1 pieceandProduct information "HW3010420 Hobbywing Ezrun MAX5 HV G2 ESC 250 A, 6-12s LiPo, BEC 8A"The EzRun MAX5 HV G2 is an impressive brushless controller with high-voltage capability. With support for up to 12S LiPo and a maximum output current of 250A, it delivers explosive performance and outstanding linearity. Thanks to intelligent freewheel technology, the speed control remains relaxed and cool even during demanding driving manoeuvres.  This controller is protected against water and dust in accordance with the IP 67 standard. As a result, the MAX5 HV G2 is naturally suitable for use in all weather conditions and can be operated on various surfaces such as mud, sand, ice, snow and water without damaging the power unit. With a powerful integrated BEC, an anti-spark design and multi-directional protection, this controller offers advanced features and high safety. The EzRun MAX5 HV G2 is the ideal choice for RC enthusiasts looking for maximum potential and reliability. By recording and storing real-time data, the operating status can even be monitored. And the upgrade of the sensor cable interface greatly improves the protection and waterproof performance of the controller. With perfect compatibility with Hobbywing's EzRun 56118 SD G2 motor, this power system offers an unbeatable team for optimum performance and protection against overheating.Features - Now with even more power than its predecessor. - Water & dust proof for use in all weather conditions. - Built-in ultra-powerful switching mode BEC to drive a wide range of servos (high power / high voltage servo). - Turbo timing setting included. Especially recommended with the matching motor (e.g. EZRUN 56118SD G2). - Several protective functions: Battery undervoltage protection, controller and motor overheating protection, signal loss protection, current protection. - Supports LED programme card, LCD G2 programme box and the OTA programming module for easier setting of controller parameters. - Data logging function to display various running data in the HW LINK app using the OTA Bluetooth module. - Supports controller firmware upgrade (multifunction LCD-G2 programme box or OTA programming module required for purchase). - Capacitor capacity increased by 45%. - 12 adjustable parameters.technical Data :Type: 1/5 Brushless Sensored Current (continuous/short): 250A / 1600A Input voltage: 6-12S LiPo BEC: 6V/7.4V/8.4V @8A (switch mode) Motor types: Brushless motors (with/without sensor) Motor limits: - 8S Lipo: KV <= 1200 - 12S Lipo: KV <= 800 56118 motor Fan: Yes, operated via the BEC Programming: LED programming card LCD programming box (G2) OTA programming module Separate programming connection Waterproof: Yes Output: 8.00mm Bullet Connector (female) Size: 94.5x59.4x50.9mm Weight: 428.5g Applications: 1/5 buggy, truck Scope of delivery:  Ezrun MAX5 HV G2 ESCBUILD YOUR OWN ORIGINAL,AUTHENTIC HPI BAJA 5BHPI large scale fans, we have heard you! The one and only original HPI Baja 5B is BACK and ready for you to build from the ground up! The HPI SBK collection of Self Build Kits grows with the addition of not just one, but TWO 1/5th scale HPI kits! Fans of large scale off-road RC will be super excited to build their own gas-powered 1/5th scale Buggy with the HPI Baja 5B Self Build Kit!When the HPI Baja 5B buggy was first introduced, large scale RC was very expensive and quite difficult for the average RC hobbyist to experience. Using highly durable parts and innovative design features, HPI brought large scale off-road to new enthusiasts and ushered in a new, BIGGER era of RC!Now, YOU can build and own the legend! Experience the thrill and excitement of building a car which ends up being over 80cm (nearly 32 inches) long and weighing nearly 10kg (over 21 lb)! Just install your own engine and electronics as you build the HPI Baja 5B and you'll be ready for any adventure that comes your way!With extra-tough drivetrain parts like the viscous torque differential, super-durable composite spur gear with internal damping and all-metal drivetrain, the HPI Baja 5B is ready for your 23-32cc 2-stroke engine so you can experience the joy of gas-powered RC and up to 30-minute runtimes!The HPI Baja 5B is also equipped with extra-big and super-tough suspension parts, featuring awesome HPI durability! With its expertly designed molded composite suspension plus extra-long adjustable HD shocks, and massive high impact nylon 3-piece beadlock wheels, the Baja 5B is ready for full-speed racing on any off-road circuit!The 4mm thick 6061 aluminum monocoque chassis gives the HPI Baja 5B the classic desert racing buggy look. Precisely bent into shape for maximum strength, the chassis provides the mounting points for the engine and suspension, forming the backbone of the car. Precise steering is provided by a dual-bellcrank rack and cam-type servo saver. Aluminum parts are anodized in cool gunmetal and the classic Baja desert racer clear polycarbonate body is included in the SBK kit, ready for your custom racing scheme!The Baja 5B SBK is a great addition to your HPI collection, as well as a fabulous introduction to large scale buggies!RACING CHASSIS DESIGN & LAYOUTThe narrow channel chassis made from rigid 4mm 6061 aircraft aluminum and gives the HPI Baja 5B a classic desert racing buggy look and extreme stiffness and durability. The U-shaped chassis is protected at the rear with a thick plastic skid plate for extra protection to the motor and drivetrain.The tube roll cage is made of high impact nylon and topped with a real aluminum roof to carry on the classic looks. The roll cage is fully functional and protects the motor and internals from crash damage. The roll cage, radio box, body panels, wing, undertray and gear case are all mounted with fast access clips for easy maintenance.To finish you need:Engine with clutch and exhaustRemote control with servos and receiver batteryChargerTwo cans of Lexan paintFeatures SummaryUnassembled 1/5th scale electric-powered Off-Road BuggyStreamlined HPI Baja 5B Flux body designAdjustable motor mountAdjustable HD shock absorbersMonocoque chassisLow CG for superior handlingLong travel suspensionViscous torque oil-filled gear differentialAll-terrain tiresBeadlock wheels with metal insert hubsAluminum rear shock towerHard plastic skid platesAdjustable rear wingQuick access to all critical maintenance pointsDual bellcrank steeringCam type servo saverHex socket hardwareGunmetal anodizingFull set of rubber-sealed ball bearingsEnclosed receiver boxChassis SpecificationsOverall Length 817mmHeight: 255mmWidth: Front - 460mm; Rear - 480mmTire Track (to center of tires): Front - 395mm; Rear - 400mmWheelbase: 570mmRide Height: 76mmSuspension Travel: Front - 95mm; Rear - 100mmWeight: 9.6kg (21.3lb)Adjustable Camber: front - shims; rear - screwFront caster: adjustable with shim 22 / 25.5* / 29 degrees (* stock)Toe-in: Front adjustable with tie rod; Rear adjustable with inserts 0-4 degrees (3 degrees stock set-up)Aircraft aluminum 6061 T6 monocoque chassisDouble wishbone suspension with adjustable roll center F/RDrive system: HD metal gears with sealed gear box (8.382:1 gear ratio)Differential: viscous torque control with 4 pinion gears; sealed diff case with silicone oilShock absorber: HD Aluminum coilover shock absorber with fully adjustable preload collarWheel type: 3-piece beadlock design, high impact nylon material with inset heavy-duty metal hex hub

For converting the Sportsline 2wd 510 touring car into a model with 4WD drive.  The conversion kit contains all chassis parts and drive parts required for the conversion.Attention!Only suitable for new FG Sportsline 510 models with vertical engine and new fronr axle with housing.Not suitable for older FG Sportsline models with horizontal engine.

y1549 ZTW Beast Pro 300A 12S ESC Features:Enchanced throttle response, excellent acceleration, linearity and driveabilityUsind the advanced PC interface allows you to set up, program or update the firmwareFully Programmable via LCD program card, PC interfaceAdjustable BEC output 6.0/7.4V, up to 8A current outputMultible protection features: Low voltage cut-off protection, over-heat protection and throttle signal loss protectionSpecification:Continuous Current: 300ABurst Current: 1800ABEC: 6,0 V/7,4 V einstellbar / 8 ABattery NIXX / LiPo: 18 - 36NC / 6-12S LiPoWidth: 74 mmLength: 115 mmHeight: 78 mmWeight: 500gProgrammable: JaWaterproof: splash proofTT70120 Top Tuning Beast Brushless Motor 620 kVSpecifications:Max. Amps: 200AMax. Voltage: 8-14SMax. Power: 10.000WKV (RPM/Volt): 620KVResistance: 0,0095Mounting hole depth: 8 mmCase diameter: 70 mmCase length: 120 mmFree shaft length: 30 mmShaft diameter: 8 mmGewicht: 1730gFeatures:High Quality BearingsRotor-4Pole High Quality MagnetsStator-Super Thin Silicon Steels Super Strength 8mm ShaftCNC Aluminium Heatsink ShellCopper Wires Of High Temperature EnduranceContents:1 set

1 pair of new PMT Kronos 30 tyres, medium hard with insert (without rims)  width 65mm  diameter 120mm  1 pair Condition new, see photos

Off-Road tires mounted and glued on rims, on chrome rims. Due to the high torque load on the bonding of tires on largescale cars, checking the bonding from time to time and re-glueing (y0067) if necessary is unavoidable.Dimensions:Diameter: 150 mmWidth: 60 mmWheel square: 18 mmContents:4 pieces / 2 pairs
