HW30105100 Hobbywing Ezrun MAX6 G2 sensored ESC 200 Amp, 3-8s LiPo, BEC 8A

The EzRun MAX5 HV G2 is an impressive brushless controller with high-voltage capability. With support for up to 12S LiPo and a maximum output current of 250A, it delivers explosive performance and outstanding linearity. Thanks to intelligent freewheel technology, the speed control remains relaxed and cool even during demanding driving manoeuvres.  This controller is protected against water and dust in accordance with the IP 67 standard. As a result, the MAX5 HV G2 is naturally suitable for use in all weather conditions and can be operated on various surfaces such as mud, sand, ice, snow and water without damaging the power unit. With a powerful integrated BEC, an anti-spark design and multi-directional protection, this controller offers advanced features and high safety. The EzRun MAX5 HV G2 is the ideal choice for RC enthusiasts looking for maximum potential and reliability. By recording and storing real-time data, the operating status can even be monitored. And the upgrade of the sensor cable interface greatly improves the protection and waterproof performance of the controller. With perfect compatibility with Hobbywing's EzRun 56118 SD G2 motor, this power system offers an unbeatable team for optimum performance and protection against overheating.Features - Now with even more power than its predecessor. - Water & dust proof for use in all weather conditions. - Built-in ultra-powerful switching mode BEC to drive a wide range of servos (high power / high voltage servo). - Turbo timing setting included. Especially recommended with the matching motor (e.g. EZRUN 56118SD G2). - Several protective functions: Battery undervoltage protection, controller and motor overheating protection, signal loss protection, current protection. - Supports LED programme card, LCD G2 programme box and the OTA programming module for easier setting of controller parameters. - Data logging function to display various running data in the HW LINK app using the OTA Bluetooth module. - Supports controller firmware upgrade (multifunction LCD-G2 programme box or OTA programming module required for purchase). - Capacitor capacity increased by 45%. - 12 adjustable parameters.technical Data :Type: 1/5 Brushless Sensored Current (continuous/short): 250A / 1600A Input voltage: 6-12S LiPo BEC: 6V/7.4V/8.4V @8A (switch mode) Motor types: Brushless motors (with/without sensor) Motor limits: - 8S Lipo: KV <= 1200 - 12S Lipo: KV <= 800 56118 motor Fan: Yes, operated via the BEC Programming: LED programming card LCD programming box (G2) OTA programming module Separate programming connection Waterproof: Yes Output: 8.00mm Bullet Connector (female) Size: 94.5x59.4x50.9mm Weight: 428.5g Applications: 1/5 buggy, truck Scope of delivery:  Ezrun MAX5 HV G2 ESC

A great motor/ESC combo, ideal for 1/5 touring cars and Formula 1 RC cars. Product information "TT5682/01 Top Tuning Brushless Motor 980 kV" Genuine Top Tuning spare/option part. Specifications Max. amps: 160 A Max. voltage: 30 V Max. power: 4,200 W KV (RPM/Volt): 980 KV Mounting hole depth: 8 mm Bolt pattern: 4 x M4 at 30 mm pitch circle diameter Case diameter: 57.8 mm Case length: 82 mm Free shaft length: 30 mm Shaft diameter: 8 mm Weight: 880 g Connector: 6.5 mm diameter Cable size: 8AWG Features High quality bearings 4Pole rotor with high quality magnets Stator - super thin silicon steel layers Super strength 8 mm shaft CNC Aluminium heatsink case Copper wires with high temperature endurance Contents:1 piece Product information "HW30105100 Hobbywing Ezrun MAX6 G2 sensored ESC 200 Amp, 3-8s LiPo, BEC 8A" The EzRun MAX6 G2 is a modern brushless controller with high-voltage support and an integrated Bluetooth module. Compared to its predecessor model, the second generation is considerably more powerful with up to 200A and, with 12 programmable parameters, also offers more scope for customisation to suit your personal driving style. Aggressive starts, high acceleration on straight stretches and jump control are just a fraction of what the controller has to offer. And thanks to the intelligent freewheel technology, the controller remains relaxed and cool even during these demanding manoeuvres. Probably the most convincing feature of the MAX6 G2 controller is the integrated Bluetooth module. This eliminates the need for programming cards and the OTA module as additional accessories. All you need now is the HWLink2 app and the controller can be conveniently programmed and updated on your smartphone. It is even possible to record data for up to 10 minutes and provides an insight into the most important driving data such as speed, voltage and temperature. With a powerful integrated BEC, an anti-spark design and several protective devices, this speed controller offers advanced functions and a high level of safety. The EzRun MAX6 G2 is therefore the ideal choice for RC enthusiasts looking for maximum potential and the best reliability. With perfect compatibility with both Hobbywing's EzRun 4990 G2 and 5690 G2 motors, this power system offers an unbeatable team for optimum performance with modern features. Features  - Now with even more power than its predecessor. - Integrated Bluetooth module to programme the controller directly via the HWLink2 app on your smartphone. - Intelligent fan that only activates when the temperature reaches a certain value. Water & dust resistant to IP67 standard for use in all weather conditions. - Built-in ultra-strong switching mode BEC to address a wide range of servos (high power / high voltage servo). - Turbo timing setting included. - Especially recommended with the matching motor (e.g. EZRUN 4990 G2 or 5690 G2). - Several protective functions: Battery undervoltage protection, controller and motor overheating protection, signal loss protection, current protection. - Built-in data logging function to display various running data of up to 10min in the HW LINK app - Supports firmware upgrade of the controller. - 12 adjustable parameters.Technical Data  Type: 1/6 Brushless Sensored Current (continuous/short): 200A / 1200A Input voltage: 3-8S LiPo BEC: 6V/7.4V/8.4V @8A (switch mode) Motor types: Brushless motors (with/without sensor) Motor limits: - 6S Lipo: KV <= 2400 - 8S Lipo: KV <= 1700 4990/5690 motor Fan: Yes, operated via the BEC Programming: HWLink2 app (via the integrated Bluetooth module) Waterproof: Yes Size: 70x56x45.5mm Weight: 245g Applications: 1/6, 1/7 on-road, truck, monster truck Scope of delivery:  Ezrun MAX6 HV G2 ESC

Genuine Top Tuning spare/option part. Specifications Max. amps: 160 A Max. voltage: 30 V Max. power: 4,200 W KV (RPM/Volt): 980 KV Mounting hole depth: 8 mm Bolt pattern: 4 x M4 at 30 mm pitch circle diameter Case diameter: 57.8 mm Case length: 82 mm Free shaft length: 30 mm Shaft diameter: 8 mm Weight: 880 g Connector: 6.5 mm diameter Cable size: 8AWG Features High quality bearings 4Pole rotor with high quality magnets Stator - super thin silicon steel layers Super strength 8 mm shaft CNC Aluminium heatsink case Copper wires with high temperature endurance Contents:1 piece

Product information "Hobbywing Ezrun MAX4 HV Combo 70125 560kV"The Ezrun MAX4 ESC works best with the included 70125 SD 560kV motor for extra large 1/4 and 1/5 scale models. This fully sensor-controlled combo can be used in many ways in such models, whether it's a heavy-duty off-roader or a truck.So if you like large models and You want the most fun out of it, the MAX4 combo is high-quality equipment that literally bursts with exploding power. And even with its enormous size, care was taken to use high-quality and, above all, durable materials in the construction. After all, both the ESC and the motor should ensure that driving fun lasts as long as possible. Even the electronic switch is well protected against damage. In addition, the Ezrun MAX4 has a built-in super high-current BEC, which can provide a max. output power of up to 25A. The output voltage can be switched between 6V, 7.4V and 8.4V. The high-current BEC was developed in such a way that it can supply the current high-current servos with sufficient power if required, and thus be able to precisely control the appropriate large models.Features:Full sensored comboSuper powerful switch mode BEC with a constant current of 10A, instant 25A and the ability to switch between 6V, 7.4V and 8.4VFireproof circuitry to protect the battery connector, as well as many built-in protectionsVersatile programmableReal time data recordingCNC-milled aluminum housing, 0.2mm silicon steel sheets and other high-quality building materialsFour sintered NdFeB magnets for super torque, stable performance and explosive powerInnovative new sensor interfaceWaterproof and dustproof thanks to the rubber cover of the bearingsIndependent, high-precision encoder in the motor to communicate the rotor position without any interferenceMore power and less heat development with the same loadTechnical Specifications:ESCCurrent (cont./peak)300A / 2000AMotor Type:Sensor/Sensorless Brushless MotorsMotor Limit:12S LiPo: kV <= 600 (70125)Cells:6-12SBEC:6V / 7.4V / 8.4V @ 10A (adjustable)Fan:Yes (powered by BEC)Programming Input:Fan/ PRG-InputProgramming:LED Programm Card, LCD Programm Box, OTA Bluetooth Programm ModuleDimensions:125x85x61.7mmWeight:775.4gApplication:1/4 and 1/5 Heavy Duty-Off-Road, TrucksMotorSensor Type:SensoredPoles:4kV Rating:560kVCells:8-12SNo-Load Current:3.6AOuter Diameter:70mmLength:125mmShaft Diameter:8mmShaft Length:30mmWeight:1995gApplication:1/5 Heavy Duty Off-Road, TruckDelivery:1x EzRun MAX4 ESC1x EzRun 70125SD Motor with 560kV1x Manual

The Ezrun Max4 controller is suitable for particularly large 1:4 and 1:5 scale models. This controller is ideal for use in any of these models, whether heavy-duty off-roaders or trucks. It is the ideal choice for high-end models that are subject to high demands or are operated aggressively.  Despite the enormous size, care was taken to use high-quality and, above all, durable materials in the construction. This can be seen, for example, in the fact that the Max4 controller is excellently protected against dust, water and similar external influences. The electronic switch is also optimally protected against damage that could otherwise occur during a normal ride. In addition, the Ezrun Max4 has a built-in super high-current BEC that can provide a maximum output power of up to 25A. The output voltage can therefore be switched between 6V, 7.4V and 8.4V. The high-current BEC was developed to supply the latest high-current servos with sufficient power on request and thus to be able to precisely control the appropriate large models.  Features - Super-strong switch mode BEC with a constant current of 10A, instant 25A and the ability to switch between 6, 7.4 and 8.4V - Fireproof circuits to protect the battery connector - Additional built-in protection mechanisms: undervoltage, overheating, signal loss, ... - Versatile programmability - Real-time data recording Technical data: Current (continuous/short) 300A / 2000A Motor type: Sensor/sensorless brushless motors Motor limit: 12S LiPo: kV &lt;= 600 (70125 size) LiPo cells: 6-12S BEC: 6V / 7.4V / 8.4V with 10A (switchable) Fan: Yes (supply via built-in BEC) Programming input: Fan / PRG input Programming: LED programming card, LCD programming box, OTA programming module Size: 125x85x61.7mm Weight: 775.4g Application: 1/4 and 1/5 Heavy Duty-Off-Road, Trucks

Product information "Hobbywing Ezrun MAX5 HV Combo 56118SD 650kV G2"Discover impressive performance with the second generation of the Ezrun MAX5 HV G2 ESC - now available in the combo version with the matching 56118SD G2 motor with 650kV! This enhanced MAX5 series with 250A offers numerous innovations, making the driving experience with 1/5th scale buggies and trucks even more thrilling.Compared to the regular MAX5 combo, the sensor mode has been significantly improved and equipped with a waterproof cable for reliable performance. The power has been increased by a whopping 18%, while reducing heat generation, resulting in even more power and efficiency. The ESC's strong, explosive, and stable output power, along with excellent low-speed linearity, ensures it excels in various applications. Quick acceleration, high-speed maneuvers, jumps, and slower driving are no problem at all. Overall, the ESC has been so greatly improved that you won't want to look back. Especially when paired with the EZRUN 56118SD G2 motor, you also benefit from motor overheating protection and turbo timing adjustment.It's the perfect way to dive right into the 1/5th scale world with ease!Features:Built-in ultra-strong switching mode BEC to support various servos.Up to 24° of turbo timing adjustment (when using a 56118 G2 motor).Data logging function.12 adjustable parameters.Increased capacitor capacity by 45%.New waterproof sensor cable.Fully sensored system for enhanced acceleration and more powerful performance.With the EZRUN 56118SD G2 motor, the MAX5 HV G2 features integrated motor overheat protection.Easy-to-disassemble motor for maintenance work.Technical Specifications:ESCType:Brushless SensoredCurrent (cont./peak):250A / 1600ANo. of Cells:6-12S LiPoMotor Limit:8S Lipo: KV <= 120012S Lipo: KV <= 800 56118 MotorBEC:6V/7.4V/8.4V @8A (Switch Mode)Fan:Yes (BEC)Programming:LED Program CardLCD Programming Box (G2)OTA Bluetooth ProgrammerSeperate Programming PortWaterproof:YesDimensions:94.5x59.4x50.9mmWeight:428.5gApplication:1/5 Buggy, TruckMotorType:Brushless, SensoredkV Rating:650kVNo-Load Current:5.5ANo. of Cells:8-12S LiPoPoles:4Diameter:56mmLength:119.2mmShaft Diameter:8mmShaft Length:30mmWeight:1272gApplication:1/5 Buggy, TruckDelivery:1x Ezrun MAX5 HV G2 ESC with 250A1x 56118SD G2 Motor with 650kV1x Manual

Product information "Hobbywing OTA Bluetooth Programer"Thanks to the OTA Programming Module, Hobbywing ESCs can be programmed in a new modern and intuitive way. The ESC is wirelessly connected to a smartphone via the Bluetooth signal sent by the module. All parameters can then be selected and set as usual in the Hobbywing "HW Link" app.The OTA programming module is also smaller and lighter than a conventional programming box and therefore fits comfortably in any pocket. So perfect for on the go.FeaturesEasy to operateCompact designData Recording in real time (compatible ESC required)Firmware-Update within the "HW Link"-AppInclusive Reset-Button on the bottom sideSuitable for the following HobbyWing productsselected XERUN and EZRUN-ESCs for RC carsselected PLATINUM-ESCs for RC aircraftsselected SEAKING-ESCs for RC BoatsTechnical SpecificationsDimensions:30x25.5x8.5mmWeight:10.2gWorking Voltage:5-12.6VEffective Range:0-3mSupported Bluetooth-Version:>/= 4.0 Notice: You can download the "HW Link"-App by Hobbywing for Android-Devices in the Google Play Store as well as for IOS-Devices in the Apple Store.
