164100RZ FG Sportsline 2WD 530er Wheelbase, Zenoah G230 Engine, RTR
Product number:
fg_164100rz
EAN:
4058575128397
Product information "164100RZ FG Sportsline 2WD 530er Wheelbase, Zenoah G230 Engine, RTR"
Genuine FG spare/option part.
The following items are required for completion: body mounts, body.
The models are built on a 4mm aluminium chassis with double wishbones front and rear. All borings are countersunk. The models are equipped with front disk brakes for an optimal braking power. Fully adjustable front and rear double wishbone suspensions.
Further equipment points are : differential gear, central brake with oversized disk, oil-pressure shock absorbers with volume control and external adjusting ring for the initial tension of the spring. All rotating parts on ball bearings. The body parts are made of clear polycarbonate. Tires are glued on the rims. The models are driven by a 23ccm engine with a powerincreasing tuned pipe. The engine runs with a 2-stroke petrol-oil mixture. Through the installed pull-start system the engine can be started without any problem. The tank capacity enables you to run your model around 45 minutes.
RTR version :
Radio system 2.4GHz
Steering metal gear servo 25kg
Gaz/Throttle servo 10kg
Radio supplied with 8 stick battery and one charger
The following items are required for completion: body mounts, body.
The models are built on a 4mm aluminium chassis with double wishbones front and rear. All borings are countersunk. The models are equipped with front disk brakes for an optimal braking power. Fully adjustable front and rear double wishbone suspensions.
Further equipment points are : differential gear, central brake with oversized disk, oil-pressure shock absorbers with volume control and external adjusting ring for the initial tension of the spring. All rotating parts on ball bearings. The body parts are made of clear polycarbonate. Tires are glued on the rims. The models are driven by a 23ccm engine with a powerincreasing tuned pipe. The engine runs with a 2-stroke petrol-oil mixture. Through the installed pull-start system the engine can be started without any problem. The tank capacity enables you to run your model around 45 minutes.
RTR version :
Radio system 2.4GHz
Steering metal gear servo 25kg
Gaz/Throttle servo 10kg
Radio supplied with 8 stick battery and one charger
