BJ012 GPM Aluminum transmission case for HPI Baja / Carson Wild GP Attack
Product information "BJ012 GPM Aluminum transmission case for HPI Baja / Carson Wild GP Attack"
Genuine GPM spare/option part.
High quality cnc machined parts made by GPM Racing Products from high strength billet aluminum. Fits all vehicles from the HPI Baja 5 line and Carson Wild GP Attach.
Contents:
High quality cnc machined parts made by GPM Racing Products from high strength billet aluminum. Fits all vehicles from the HPI Baja 5 line and Carson Wild GP Attach.
Contents:
- 1 piece
